| 型号 | 尺寸mm | 额定电压VAC | 频率Hz | 转速rpm | 输入功率W | 额定输入电流A | 温度范围℃ | 防护等级 | 绝缘等级 |
|---|---|---|---|---|---|---|---|---|---|
| RCBH175-E23TT-42D | 175 | 1~230±10% | 50/60 | 2707/3027 | 58/73 | 0.26/0.32 | -25~70 | IP54 | F |
| RCBH180-E23TT-30D | 180 | 1~230±10% | 50/60 | 2696/3020 | 60/81 | 0.27/0.35 | -25~70 | IP54 | F |
| RCBH190-E23TT-44D | 190 | 1~230±10% | 50/60 | 2493/2630 | 64/82 | 0.28/0.36 | -25~70 | IP54 | F |
| RCBH220-E23VT-44D | 220 | 1~230±10% | 50/60 | 2473/2416 | 106/144 | 0.47/0.63 | -25~70 | IP54 | F |
| RCBH225-E23BT-63D | 225 | 1~230±10% | 50/60 | 2593/2674 | 162/230 | 0.74/1.01 | -25~70 | IP54 | F |
| RCBH220-E23VT-44D | 220 | 1~230±10% | 50/60 | 2544/2713 | 167/228 | 0.75/0.99 | -25~70 | IP54 | F |
| RCBH225-E23BT-63D | 225 | 1~230±10% | 50/60 | 2634/2900 | 163/217 | 0.35/0.36 | -25~70 | IP54 | F |
| RCBH250-E23WT-52D | 250 | 1~230±10% | 50/60 | 2674/3011 | 199/270 | 0.91/1.19 | -25~70 | IP54 | F |
| RCBH250-E23WT-52D | 250 | 1~230±10% | 50/60 | 2536 | 241 | 1.06 | -25~70 | IP54 | F |
| RCBH250-D23WT-52D | 250 | 3~400V±10% | 50/60 | 2549/2718 | 207/288 | 0.36/0.45 | -25~70 | IP54 | F |
| RCBH280-D26D_87_ (With Long Inlet Ring) | 280 | 3~400V±10% | 50 | 2775 | 690 | 1.84 | -25~65 | IP54 | F |
| RCBH280-D26D_-87_ (With short Inlet Ring) | 280 | 3~400V±10% | 50/60 | 2710 | 610 | 1.29 | -25~65 | IP54 | F |
| RCBH280-DF6D_-87_ (With Long Inlet Ring) | 280 | 3~400V±10% | 50 | 2696/2282 | 600/420 | 1.32/0.68 | -25~65 | IP54 | F |
| RCBH280-DF6D_-87_ (With short Inlet Ring) | 280 | 3~400V±10% | 50/60 | 2694/2262 | 610/440 | 1.30/0.70 | -25~65 | IP54 | F |
| RCBH280-E26D_-87_ (With Long Inlet Ring) | 280 | 1~230±10% | 50 | 2657 | 620 | 2.76 | -25~55 | IP54 | F |
| RCBH280-E26D_-87_ (With short Inlet Ring) | 280 | 1~230±10% | 50 | 2644 | 620 | 2.79 | -15~65 | IP54 | F |
| RCBH315-D26D_-70_ (With Long Inlet Ring) | 315 | 3~400V±10% | 50 | 2621 | 750 | 1.45 | -25~60 | IP54 | F |
| RCBH315-D26D_-70_ (With Short Inlet Ring) | 315 | 3~400V±10% | 50 | 2629 | 740 | 1.42 | -25~60 | IP54 | F |
| RCBH315-DF6D_-70_ (With Long Inlet Ring) | 315 | 3~400V±10% | 50 | 2579/2079 | 750/510 | 1.436/0.81 | -25~60 | IP54 | F |
| RCBH315-DF6D_-70_ (With Short Inlet Ring) | 315 | 3~400V±10% | 50 | 2612/2108 | 730/490 | 1.42/0.78 | -25~60 | IP54 | F |
| RCBH315-D27B_-98_ (With Long Inlet Ring) | 315 | 3~400V±10% | 50 | 2665 | 1110 | 1.89 | -25~70 | IP54 | F |
| RCBH315-D27B_-98_ (With Short Inlet Ring) | 315 | 3~400V±10% | 50 | 2656 | 990 | 1.70 | -25~70 | IP54 | F |
| RCBH315-D46B_-98_ (With Long Inlet Ring) | 315 | 3~400V±10% | 50 | 1439 | 220 | 0.83 | -25~70 | IP54 | F |
| RCBH315-D46B_-98_ (With Short Inlet Ring) | 315 | 3~400V±10% | 50 | 1447 | 190 | 0.69 | -25~70 | IP54 | F |
| RCBH315-DG6B_-98_ (With Long Inlet Ring) | 315 | 3~400V±10% | 50 | 1427/1300 | 170/140 | 0.52/0.28 | -25~70 | IP54 | F |
| RCBH315-DG6B_-98_ (With Short Inlet Ring) | 315 | 3~400V±10% | 50 | 1431/1308 | 170/130 | 0.52/0.27 | -25~70 | IP54 | F |
| RCBH315-E46B_-98_ (With Long Inlet Ring) | 315 | 1~230±10% | 50 | 1428 | 210 | 1.14 | -15~65 | IP54 | F |
| RCBH315-E46B_-98_ (With Short Inlet Ring) | 315 | 1~230±10% | 50 | 1439 | 210 | 0.98 | -15~65 | IP54 | F |
| RCBH355-D27G_-110_ (With Long Inlet Ring) | 355 | 3~400V±10% | 50 | 2739 | 1980 | 3.44 | -25~65 | IP54 | F |
| RCBH355-D27G_-110_ (With Short Inlet Ring) | 355 | 3~400V±10% | 50 | 2770 | 1810 | 3.18 | -25~65 | IP54 | F |
| RCBH355-DF7G_-110_ (With Long Inlet Ring) | 355 | 3~400V±10% | 50 | 2757/2197 | 1970/1400 | 3.41/2.43 | -25~65 | IP54 | F |
| RCBH355-DF7G_-110_ (With Short Inlet Ring) | 355 | 3~400V±10% | 50 | 2783/2278 | 1830/1340 | 3.21/2.31 | -25~65 | IP54 | F |
| RCBH355-D46B_-110_ (With Long Inlet Ring) | 355 | 3~400V±10% | 50 | 1397 | 300 | 0.84 | -25~70 | IP54 | F |
| RCBH355-D46B_-110_ (With Short Inlet Ring) | 355 | 3~400V±10% | 50 | 1415 | 270 | 0.74 | -25~70 | IP54 | F |
| RCBH355-DG6B_-110_ (With Long Inlet Ring) | 355 | 3~400V±10% | 50 | 1371/1148 | 290/210 | 0.64/0.38 | -25~70 | IP54 | F |
| RCBH355-DG6B_-110_ (With Short Inlet Ring) | 355 | 3~400V±10% | 50 | 1386/1183 | 250/190 | 0.57/0.35 | -25~70 | IP54 | F |
| RCBH355-E46B_-110_ (With Long Inlet Ring) | 355 | 1~230±10% | 50 | 1381 | 300 | 1.44 | -25~70 | IP54 | F |
| RCBH355-E46B_-110_ (With Short Inlet Ring) | 355 | 1~230±10% | 50 | 1394 | 270 | 1.33 | -15~65 | IP54 | F |
| RCBH355-E46D_-110_ (With Long Inlet Ring) | 355 | 1~230±10% | 50 | 1421 | 350 | 2.03 | -15~65 | IP54 | F |
| RCBH355-E46D_-110_ (With Short Inlet Ring) | 355 | 1~230±10% | 50 | 1423 | 350 | 2.03 | -15~65 | IP54 | F |
| RCBH355-E46D_-110_ (With Long Inlet Ring) | 355 | 1~230±10% | 50 | 1421 | 350 | 2.03 | -15~65 | IP54 | F |
| RCBH400-D46D_- 123_ (With Short Inlet Ring) | 400 | 1~230±10% | 50 | 1363 | 470 | 1.14 | -25~65 | IP54 | F |
| RCBH400-DG6D_-123_ (With Long Inlet Ring) | 400 | 3~400V±10% | 50 | 1373/1141 | 490/340 | 1.27/0.68 | -25~65 | IP54 | F |
| RCBH400-DG6D_-123_ (With Short Inlet Ring) | 400 | 3~400V±10% | 50 | 1359/1119 | 470/320 | 1.22/0.65 | -25~65 | IP54 | F |
| RCBH400-E46F_-123_ (With Long Inlet Ring) | 400 | 1~230±10% | 50 | 1347 | 490 | 2.40 | -15~75 | IP54 | F |
| RCBH400-E46F_-123_ (With Short Inlet Ring) | 400 | 1~230±10% | 50 | 1362 | 520 | 2.34 | -15~75 | IP54 | F |
| RCBH400-E46D_-123_ (With Long Inlet Ring) | 400 | 1~230±10% | 50 | 1358 | 490 | 2.44 | -15~65 | IP54 | F |
| RCBH400-E46D_-123_ (With Short Inlet Ring) | 400 | 1~230±10% | 50 | 1362 | 480 | 2.12 | -15~45 | IP54 | F |
| RCBH400-D66B_-123_ (With Long Inlet Ring) | 400 | 3~400V±10% | 50 | 942 | 190 | 0.65 | -25~70 | IP54 | F |
| RCBH400-D66B_-123_ (With Short Inlet Ring) | 400 | 3~400V±10% | 50 | 942 | 180 | 0.63 | -25~70 | IP54 | F |
| RCBH400-DH6B_-123_ (With Long Inlet Ring) | 400 | 3~400V±10% | 50 | 972/807 | 190/120 | 0.66/0.29 | -25~70 | IP54 | F |
| RCBH400-DH6B_-123_ (With Short Inlet Ring) | 400 | 3~400V±10% | 50 | 930/810 | 190/120 | 0.68/0.30 | -25~70 | IP54 | F |
| RCBH400-E66B_-123_ (With Long Inlet Ring) | 400 | 1~230±10% | 50 | 900 | 210 | 1.00 | -15~65 | IP54 | F |
| RCBH400-E66B_-123_ (With Short Inlet Ring) | 400 | 1~230±10% | 50 | 909 | 200 | 1.08 | -15~70 | IP54 | F |
| RCBH450-D46F_-115_ (With Long Inlet Ring) | 450 | 3~400V±10% | 50 | 1351 | 780 | 1.51 | -25~60 | IP54 | F |
| RCBH450-D46F_-115_ (With Short Inlet Ring) | 450 | 3~400V±10% | 50 | 1353 | 770 | 1.52 | -25~65 | IP54 | F |
| RCBH450-D46F_-138_ (With Long Inlet Ring) | 450 | 3~400V±10% | 50 | 1337 | 840 | 1.65 | -25~60 | IP54 | F |
| RCBH450-D46F_-138_ (With Short Inlet Ring) | 450 | 3~400V±10% | 50 | 1359 | 790 | 1.54 | -25~60 | IP54 | F |
| RCBH450-DG6F_-138_ (With Long Inlet Ring) | 450 | 3~400V±10% | 50 | 1350/1069 | 870/620 | 1.73/1.07 | -25~55 | IP54 | F |
| RCBH450-DG6F_-138_ (With Short Inlet Ring) | 450 | 3~400V±10% | 50 | 1346/1068 | 820/580 | 1.62/1.01 | -25~55 | IP54 | F |
| RCBH450-E46F_-138_ (With Long Inlet Ring) | 450 | 1~230±10% | 50 | 1215 | 740 | 3.38 | -15~50 | IP54 | F |
| RCBH450-DG6F_-138_ (With Short Inlet Ring) | 450 | 1~230±10% | 50 | 1219 | 730 | 3.38 | -15~50 | IP54 | F |
| RCBH450-D66B_-138_ (With Long Inlet Ring) | 450 | 3~400V±10% | 50 | 892 | 290 | 0.72 | -25~65 | IP54 | F |
| RCBH450-D66B_-138_ (With Short Inlet Ring) | 450 | 3~400V±10% | 50 | 897 | 280 | 0.69 | -25~65 | IP54 | F |
| RCBH450-DH6B_-138_ (With Long Inlet Ring) | 450 | 3~400V±10% | 50 | 868/674 | 280/170 | 0.74/0.36 | -25~65 | IP54 | F |
| RCBH450-DH6B_-138_ (With Short Inlet Ring) | 450 | 3~400V±10% | 50 | 871/676 | 280/160 | 0.18/0.37 | -25~65 | IP54 | F |
| RCBH450-E66D_-138_ (With Long Inlet Ring) | 450 | 1~230±10% | 50 | 910 | 410 | 2.28 | -15~45 | IP54 | F |
| RCBH450-E66D_-138_ (With Short Inlet Ring) | 450 | 1~230±10% | 50 | 918 | 410 | 2.19 | -15~45 | IP54 | F |
| RCBH500-D47D_-138_ (With Long Inlet Ring) | 500 | 3~400V±10% | 50 | 1369 | 1370 | 2.72 | -25~65 | IP54 | F |
| RCBH500-D47D_-138_ (With Short Inlet Ring) | 500 | 3~400V±10% | 50 | 1371 | 1360 | 2.70 | -25~60 | IP54 | F |
| RCBH500-DG7D_-138_ (With Long Inlet Ring) | 500 | 3~400V±10% | 50 | 1358/1101 | 1490/1040 | 3.02/1.81 | -25~60 | IP54 | F |
| RCBH500-DG7D_-138_ (With Short Inlet Ring) | 500 | 3~400V±10% | 50 | 1360/1103 | 1460/1020 | 3.01/1.82 | -25~60 | IP54 | F |
| RCBH500-D47D_-155_ (With Long Inlet Ring) | 500 | 3~400V±10% | 50 | 1360 | 1400 | 2.76 | -25~55 | IP54 | F |
| RCBH500-D47D_-155_ (With Short Inlet Ring) | 500 | 3~400V±10% | 50 | 1352 | 1470 | 2.84 | -25~55 | IP54 | F |
| RCBH500-DG7D_-155_ (With Long Inlet Ring) | 500 | 3~400V±10% | 50 | 1343/1085 | 1490/1060 | 3.04/1.85 | -25~55 | IP54 | F |
| RCBH500-DG7D_-155_ (With Short Inlet Ring) | 500 | 3~400V±10% | 50 | 1346/1086 | 1480/1050 | 3.05/1.86 | -25~55 | IP54 | F |
| RCBH500-D47G_-155_ (With Long Inlet Ring) | 500 | 3~400V±10% | 50 | 1421 | 1510 | 3.35 | -25~70 | IP54 | F |
| RCBH500-D47G_-155_ (With Short Inlet Ring) | 500 | 3~400V±10% | 50 | 1418 | 1550 | 3.39 | -25~70 | IP54 | F |
| RCBH500-DG7G_-155_ (With Long Inlet Ring) | 500 | 3~400V±10% | 50 | 1419/1267 | 1540/1220 | 3.70/2.07 | -25~70 | IP54 | F |
| RCBH500-DG7G_-155_ (With Short Inlet Ring) | 500 | 3~400V±10% | 50 | 1409/1245 | 1550/1240 | 3.32/2.05 | -25~70 | IP54 | F |
| RCBH500-D66F_-155_ ( With Long Inlet Ring ) | 500 | 3~400V±10% | 50 | 906 | 490 | 1.26 | -25~65 | IP54 | F |
| RCBH500-D66F_-155_ ( With Short Inlet Ring ) | 500 | 3~400V±10% | 50 | 90 | 490 | 1.25 | -25~65 | IP54 | F |
| RCBH500-DH6F_-155_ ( With Long Inlet Ring ) | 500 | 3~400V±10% | 50 | 906/735 | 490/330 | 1.26/1.08 | -25~60 | IP54 | F |
| RCBH500-DH6F_-155_ ( With Short Inlet Ring ) | 500 | 3~400V±10% | 50 | 907/737 | 490/320 | 1.25/1.07 | -25~60 | IP54 | F |
| RCBH500-E66F_-155_ ( With Long Inlet Ring ) | 500 | 3~400V±10% | 50 | 885 | 570 | 2.61 | -15~45 | IP54 | F |
| RCBH500-E66F_-155_ ( With Short Inlet Ring ) | 500 | 3~400V±10% | 50 | 890 | 560 | 2.64 | -15~45 | IP54 | F |
| RCBH560-D47K_-132_ ( With Long Inlet Ring ) | 560 | 3~400V±10% | 50 | 1369 | 2210 | 4.24 | -15~55 | IP54 | F |
| RCBH560-D47K_-132_ ( With Short Inlet Ring ) | 560 | 3~400V±10% | 50 | 1371 | 2210 | 4.25 | -25~55 | IP54 | F |
| RCBH560-DG7K_-132_ ( With Long Inlet Ring ) | 560 | 3~400V±10% | 50 | 1369/1150 | 2110/1500 | 4.45/2.55 | -25~55 | IP54 | F |
| RCBH560-DG7K_-132_ ( With Short Inlet Ring ) | 560 | 3~400V±10% | 50 | 1377/1153 | 2190/1620 | 4.23/2.77 | -25~55 | IP54 | F |
| RCBH560-D47K_-155_ ( With Long Inlet Ring ) | 560 | 3~400V±10% | 50 | 1358 | 2480 | 4.65 | -25~50 | IP54 | F |
| RCBH560-D47K_-155_ ( With Short Inlet Ring ) | 560 | 3~400V±10% | 50 | 1358 | 2470 | 4.61 | -25~50 | IP54 | F |
| RCBH560-DG7K_-155_ ( With Long Inlet Ring ) | 560 | 3~400V±10% | 50 | 1346/1086 | 2470/1710 | 4.90/2.91 | -25~50 | IP54 | F |
| RCBH560-DG7K_-155_ ( With Short Inlet Ring ) | 560 | 3~400V±10% | 50 | 1360/1116 | 2430/2930 | 4.54/2.93 | -25~50 | IP54 | F |
| RCBH560-D67D_-155_ ( With Long Inlet Ring ) | 560 | 3~400V±10% | 50 | 903 | 810 | 2.00 | -25~60 | IP54 | F |
| RCBH560-D67D_-155_ ( With Short Inlet Ring ) | 560 | 3~400V±10% | 50 | 903 | 810 | 2.00 | -25~60 | IP54 | F |
| RCBH560-D67D_-174_ ( With Long Inlet Ring ) | 560 | 3~400V±10% | 50 | 890 | 890 | 2.07 | -25~55 | IP54 | F |
| RCBH560-DH7D_-174_ ( With Short Inlet Ring ) | 560 | 3~400V±10% | 50 | 864/673 | 780/450 | 2.07/0.98 | -25~60 | IP54 | F |
| RCBH560-DH7D_-174_ ( With Long Inlet Ring ) | 560 | 3~400V±10% | 50 | 860/670 | 790/470 | 2.05/0.95 | -25~60 | IP54 | F |
| RCBH560-DH7D_-174_ ( With Short Inlet Ring ) | 560 | 3~400V±10% | 50 | 864/673 | 780/450 | 2.07/0.98 | -25~60 | IP54 | F |
| RCBH630-D48L_-158_ ( With Long Inlet Ring ) | 630 | 3~400V±10% | 50 | 1382 | 4190 | 7.37 | -25~75 | IP54 | F |
| RCBH630-D48L_-180_ ( With Long Inlet Ring ) | 630 | 3~400V±10% | 50 | 1369 | 4530 | 7.92 | -25~60 | IP54 | F |
| RCBH630-DH7K_-195_ ( With Long Inlet Ring ) | 630 | 3~400V±10% | 50 | 862/662 | 1360/850 | 3.32/1.64 | -25~65 | IP54 | F |
| RCBH710-D68J_-195_ ( With Long Inlet Ring ) | 710 | 3~400V±10% | 50 | 869 | 2550 | 5.05 | -25~60 | IP54 | F |
| RCBH710-D68L_-219_ ( With Long Inlet Ring ) | 710 | 3~400V±10% | 50 | 910 | 2840 | 6.15 | -25~60 | IP54 | F |
| RCBH710-DH8J_-219_ ( With Long Inlet Ring ) | 710 | 3~400V±10% | 50 | 917 | 2620 | 5.56 | -25~60 | IP54 | F |
